Pitney Bowes Relay 5000 - Manual Feeder

2-8 SV63136 Rev. A
2 • Meet the Inserting System
Use the manual feeder to hand feed stapled or unstapled sets of up to five
sheets. The machine waits for each set to be manually fed before folding
and inserting the set into the envelope.
NOTES:
• The feeder type of the item (to be fed manually) in the current job has to be
dened as manual for the feature to work.
• The job with the manual fed piece can also include items from other feeders,
including sheets or inserts.
To use the manual feeder:
1. Select a job that uses the manual feeder.
2. Push the Manual Feed lever up.
3. Press TRIAL PIECE to start the inserter.
4. Feed each set by pushing the edge into the rollers one at a time.
5. Push the lever down when you are done.
Manual Feeder
Figure 2.4: Manual Feed Lever.
Push the
Manual Feed
lever up.
