SV63136 Rev. A
6-3
Specifications • 6
Overview
Dimensions
All dimensions are approximate.
Length overall, height Weight, unboxed
Relay 5000
89" (2261 mm), 31" (787 mm) 327 lbs. (148 kg)
Relay 8000
89" (2261 mm). 33.5" (851 mm) 350 lbs. (158 kg)
High Capacity Sheet
Feeder (HCSF)
43.5" (1105 mm), 28.6" (726 mm) 150 lbs. (68 kg)
Vertical Power Stacker
17" (432 mm), 24" (610 mm) 21 lbs. (18.6 kg)
Exit Transport
20" (508 mm), 16" (406 mm) 52 lbs. (24 kg)
Flats Sealer
12.5" (317mm), 16" (406 mm) 82 lbs. (180.4 kg)
Environmental Limits
Temperature F (C) Humidity % Wet Bulb
Temp. F (C)
Minimum Maximum Minimum Maximum Maximum
Normal Operating
Conditions
60 (16) 75 (24) 30 60 N/A
Extended Operating
Conditions
50 (10) 95 (35) 08 85 85 (29)
Storage Conditions 15 (-09) 120 (49) 05 95 85 (29)
Shipping Conditions -40 (-40) 140 (60) 05 100 85 (29)
This section lists specifications for the system, its hardware components,
and the materials that are compatible for use in the system.
System
Specifications
