Pitney Bowes Relay 5000 - Setting up a BCR Scan Configuration

SV63136 Rev. A
8-15
Scanning • 8
To set up a BCR Scan Configuration:
1. From the Home screen, select Menu>Tools.
2. Select Configure System>Scan Configuration Setup.
NOTE: If you are not logged in with supervisor or manager access rights, you
will be prompted to enter an access code.
3. Select the appropriate BCR Scan Type:
• Code 3 of 9
• Interleaved 2 of 5
• 2D
4. The Scan Configuration Setup screen for your selection displays. Select
Create New Item.
5. Enter the Scan Configuration name using the alphanumeric matrix.
6. Press Finished when you are done.
NOTE: The Scan Conguration name cannot be longer than 9 characters.
Additionally, all names must be unique across all scan types. That is, a BCR
Scan Conguration name cannot be the same as an OMR Scan Conguration
name.
Setting Up
a BCR Scan
Configuration
Setting Up an
OMR Scan
Configuration
(continued)
Menu Option Associated Options/Actions
LSB Allows you to specify the least significant bit.
Toggles:
• Last (default, farthest from top of page), or
• First.
When First is selected for the Least Significant Bit option, the
least significant bit is closest to the top of the page.
When Last is selected, the least significant bit is farthest from
the top of the page.
10. Select Finished once you have set all of the necessary options for the
function.
11. Repeat steps 8 to 10 for each additional function on the OMR Scan
Configuration Worksheet.
12. Select Finished on the Create Scan Code screen once you have
entered and set up all of the functions.
