Pitney Bowes Relay 5000 - Insert Trays

SV63136 Rev. A
2-7
Meet the Inserting System • 2
Insert trays feed items that do not need folding (envelopes, cards, booklets,
slips and pre-folded media) into the system. Insert Trays have a weighted
sliding mechanism known as a sled that keeps pressure on the material for
proper feeding.
Insert trays have two sets of maximum fill lines: one set for slips, and a
second set for envelopes.
Insert Trays
Figure 2.3.2: Insert Tray
Sled mechanism
