Meet the Inserting System • 2
About System
Covers
Three covers on the front side of the system, as shown here, open to
provide access to paper release knobs.
Covers on the top of the transport deck open to provide access to the rollers
in the main paper path:
Post-fold
Accumulator Cover
Insertion
Area Cover
Figure 2.7.2: Top Covers
Pre-fold
Accumulator Cover
Folder
Cover
Figure 2.7.1: Front Covers
Sealer Replacement
Cover (closed)
Tower Base Cover
(closed)
Main Transport Deck
Cover (open)
