8-18 SV63136 Rev. A
8 • Scanning
Menu Option Associated Options/Actions
Wrap At Displays “Wrap At” numeric entry screen, where you enter
the maximum code value in decimal format.
• If the count direction is Up, the next code after this value
will be 0 or 1, depending on the Includes Zero setting.
• If the count direction is Down, the code should jump to
this value after 0 or 1.
This field can contain up to 10 digits.
Includes Zero Allows you to specify whether the sequence should include
zero.
Toggles:
• Yes (default), or
• No.
When Yes is selected for the Include Zero option, the
relevant code’s binary value would allow zero, which is
represented by no marks being printed within that section of
the code.
When No is selected for the Include Zero, the relevant code
will NOT include zero as a value.
LSB Allows you to specify the least significant bit.
Toggles:
• Last (default, farthest from start of code), or
• First.
When Last is selected for the Least Significant Bit option,
the code is in the normal order, with the least significant bit is
closest to the right-hand end of the string.
When First is selected, which is very uncommon, the bits are
reversed.
8. Select Finished once you have set all of the necessary options for the
function.
9. Repeat steps #6 to 8 for each additional function on the BCR Scan
Configuration Worksheet.
10. Select Scan Mark to toggle the appropriate mark orientation (ladder or
picket), as indicated on the BCR Scan Configuration Worksheet.
NOTE: "Picket" orientation is only available when a HCSF is equipped
specically to support this option.
11. Select PC Control to toggle the appropriate option (Yes or No).
NOTE: When PC Control is set to Yes the scan grid is grayed out.
Additionally, the Increase, Decrease, and Set Options menu items are
unavailable.
12. Select Finished on the Create Scan Code screen once you have
entered and set up all of the functions.
Setting Up
a BCR Scan
Configuration
(continued)
