3-38 SV63136 Rev. A
3 • Basic Operation
Insert Options
(continued)
Length is the
dimension of the
insert in the direction
of the feed.
• Auto measure - measures the recommended length
automatically.
NOTE: Auto measure is not available when “Large Booklet” is
the selected insert or when the job requires a Custom Feeder.
• Custom Length - allows increase or decrease of insert length.
- Use the UP/DOWN Arrow Keys to select number.
- Select "Accept" when done.
NOTE: If the job requires a Large Booklet, you must enter the
sheet length using this Custom Length option. The job will not
be valid if the booklet length is not entered.
• Custom Length (Large Booklet Only) - allows selection of large
booklet size: 8.5 inch x 11 inch (216mm x 279mm) or 5.5
inches x 8.5 inches (140mm x 216mm).
NOTE: If the job requires a Large Booklet, you must enter the
sheet length using this Custom Length option. The job will not
be valid if the booklet length is not entered.
To Next Page
