Performance Diagnostics
NOTE: This section is available for both Acuity and vSTAC vPGs.
Performance Diagnostics provides an in-depth look into the performance of network connections and disk usage for the
selected Acuity vPG. This view provides Network information from a node perspective and is updated when the dropdown
menu is changed. Performance Diagnostics does not update continuously like Performance Monitor, and the view will
remain static until a variable is changed; however, multiple entities can be selected for viewing.
For the selected vPG, there are two main views: Global View and Node View. Global View separates Networks and
Storage (as well as Volumes, as applicable) into relevant sub-categories, and shows this data as pulled from the vPG.
Node View provides information on those same sub-categories specific to the chosen node.
These options all have the same basic drop-down menu at the top that allow for the selection of Time, Entities, Metrics,
Chart Type, and Scale Type.
• Time selections are contingent on vPG type and offer: 5 minutes, 1 hour, 1 day, 1 week, or 1 month.
• Entities dropdown provides different options depending on the view chosen in the navigation tree. Global View
Entities will be a list of the available nodes on which to pull this data, and Node View Entities are the same Networks
listed above in Global View. Choose one, multiple, or Select All.
• Metrics options will vary depending on the option chosen in the navigation tree. The same data sets are available two
different ways: from the Global View or Node View.
View Level Tier Category Available Metrics
Global View Networks Dednet
SAN0
SAN1
Receive bytes
Receive packets
Transmit bytes
Transmit packets
Receive multicast
Node View Networks
Global View Storage Cache
SATA
Maximum Latency (ms)
Write IOPS
Write MBPS
Total IOPS
Total MBPS
Queue Write Avg Queue Depth
Queue Write Max Queue Depth
Queue Write Percent Busy
Queue Write Avg Latency (ms)
Queue Total Avg Queue Depth
Queue Total Max Queue Depth
