4
4.19
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
3. With the ignition turned off, disconnect the wire
harness from the ECU. Lift the connector locking
lever and rotate it up until the connector is free from
the ECU.
NOTE: Upon removing the ECU connector, you
should hear a “click” when the connector is fully
open.
4. To install, reverse the procedure and tighten the
mounting screws to specification.
NOTE: Upon installing the ECU connector, you
should hear a “click” when the connector is fully
closed.
ECU Retaining Screws:
24 in-lb (3 Nm)
FUEL SYSTEM
