GENERAL INFORMATION
SPECIAL TOOLS
PART NUMBER
TOOL DESCRIPTION
2872608 Roll Pin Removal Tool
8700226
CV Boot Clamp Pliers
(earless type)
PU-48951
Axle Boot Clamp Tool
Bosch Automotive Service Solutions: 1-800-345-
2233 or http://polaris.service-solutions.com/
Final Drive Torque Specifications
ITEM SPECIFICATION
Wheel Lug Nuts 120 ft-lbs (163 Nm)
Hub Castle Nut
(front and rear)
110 ft-lbs (149 Nm)
Ball Joint Pinch
Fasteners
42 ft-lbs (57 Nm)
Brake Caliper
Mounting Bolts
40 ft-lbs (54 Nm)
Tie Rod End
Fastener
15 ft-lbs (20 Nm) + 90°
Propshaft Support
Bearing Fasteners
35 ft-lb (47 Nm)
Front Gearcase
Cover Plate Screws
11 ft-lbs (15 Nm)
Front Gearcase
Mounting Bolts
30 ft-lbs (41 Nm)
Bearing Carrier to
Trailing Arm Bolts
42 ft-lb (54 Nm)
Radius Rod
Fasteners
40 ft-lb (54 Nm)
FINAL DRIVE
