7.10
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
6. Torque wheel hub nut to specification and install a
new cotter pin
. Tighten nut slightly if necessary to
align cotter pin holes.
Hub Castle Nut:
110 ft-lbs (149 Nm)
7. Install wheel and four wheel nuts. Torque wheel nuts
to specification.
Wheel Nuts:
120 ft-lbs (163 Nm)
8. Rotate wheel and check for smooth operation. Bend
both ends of cotter pin around end of spindle in
different directions.
FINAL DRIVE
