3.16
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
8. Lift the cover from the housing and remove the
thermostat.
NOTE: Thermostat has a pop-off relief to allow
the bypass system to operate until thermostat
opens.
9. Install a new thermostat with the bleed hole
positioned closest to the engine.
NOTE: Image shown above is with engine
removed for clarity.
10. Reverse this procedure for installation. Torque
thermostat cover bolts to specification.
Thermostat Cover Bolts:
7 ft-lb (10 Nm)
11. Be sure to properly fill and bleed cooling system as
outlined in this chapter.
ENGINE / COOLING SYSTEM
