power automation PA 8000 User Manual

Pin Assignment
Pin 1 Track A+
Pin 2 Track A-
Pin 3 Track B+
Pin 4 Track B-
Pin 5 Track R+
Pin 6 Track R-
Pin 7 Probe input
Pin 8 Probe ground
Pin 9/11/13/15 RMS grounding
Pin 10/12/14 +5 V RMS
Property Value Unit
Interface type RS 422
Track common
mode range
-7 - +7 V
Max. track input
voltage
-11 - +14 V
Min. track input
voltage
+/- 500 mV
Track input impe-
dance
150 Ω
Max. track fre-
quency (no filter)
5 MHz
Max. count fre-
quency (no filter)
20 MHz
External connector 15 pin Sub-D female / axis
Each measurement input is referenced against its
measurement reference.
Pin Assignment
RMS Input Characteristics
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 100
