Fig. 93: Analog input equivalent schematic
U
A/D
= (U
+IN
- U
ACOM
) - (U
-IN
- U
ACOM
)
n U
A/D
= A/D Converter Output
n U
+IN
= + Differential input
n U
-IN
= - Differential input
n U
ACOM
= Analog ground ACOM
Input Schematic
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 112
