LED state Module status
Off Default
On Bustest between control unit and the last PAMIO
module is active
LED state Module status
Off Error 1: The ambient temperature is above 60 °C
(140 °F) and all outputs are disabled by the
onboard logic
Flashing Warning: The ambient temperature is above 55 °C
(131 °F)
On Default
LED state Module status
Off Axis is not connected
OR Axis is connected and an encoder wire break has
been detected
Flashing Axis is connected and a wrong sequence of signals
on track A and B has occurred
On Axis is connected and no wire break has been
detected
NOTICE!
A wrong sequence of axis signals is detected when
the A and B track of an incremental measuring
system shows incorrect sequence of rising and
falling edges. This can occur in case of interfer-
ences on the signals.
LED "Bustest" (3)
LED "Monitor" (4)
LED "Axis 1" - LED "Axis 4" (5 - 8)
PA 8000 PAMIO
Troubleshoong
12.01.2017 | 122
