LED state Module status
Off The power supply voltage for
the onboard logic is outside its
tolerances
OR The ambient temperature is
above 60 °C (140 °F)
On The power supply voltage for
the onboard logic is OK
AND The +/- 15 V supply voltage for
the analog I/O functions is OK
AND The ambient temperature is
below 60 °C (140 °F)
LED state Module status
Off The CNC is not ready or the
power supply for the RMS is
outside of the tolerated values
or the ambient temperature is
T>55 °C (131 °F). In all these
cases, the analog outputs are
set to 0V.
On The CNC is ready, the power
supply for the RMS is OK and
the ambient temperature is
T>55°C (131°F). The analog
outputs are enabled.
LED "Power OK" (9)
LED "CNC Ready" (10)
PA 8000 PAMIO
Troubleshoong
12.01.2017 | 123
