Property Value
Cable type round twisted pair, shielded
Number of leads 50 (25 x 2)
Lead cross section
0.09 mm
2
(AWG 28)
Outside diameter 8 - 9 mm (0.3 ")
Maximum length 30 m (98 ft)
Connector types sub-D, case shielded
Connector genders male/female
Connector pins 50 (3 rows)
Connector attachment 4-40/UNC screws
NOTICE!
All cables connected to the control unit are
intended for stationary use only.
The cable shield is connected to both connector
casings.
Table 5: The one-to-one wiring between the cable's connectors is
set up as follows:
Pair Pins Pair Pins
1 = 1/34 14 = 26/10
2 = 18/2 15 = 43/27
3 = 35/19 16 = 11/44
4 = 3/36 17 = 28/12
5 = 20/4 18 = 45/29
6 = 37/21 19 = 13/46
7 = 5/38 20 = 30/14
8 = 22/6 21 = 47/31
9 = 39/23 22 = 15/48
10 = 7/40 23 = 32/16
11 = 24/8 24 = 49/33
12 = 41/25 25 = 17/50
13 = 9/42
