power automation PA 8000 User Manual

PAMIO model Value Unit
Backplane 0.1 A
2416 0.1 A
4ENC4A 0.5 A
2ENC4A 0.2 A
PAMIO PWM 0.1 A
The 24V power supply necessary for the on-board logic of the
complete I/O rack system has to be determined by making the sum
of all the components in use.
The following table shows the requirements of the standard prede-
fined combinations available from Power Automation.
PAMIO model Calculation Total Unit
PAMIO with 1x
2416
0.1+0.1 0.2 A
PAMIO with 1x
4ENC4A
0.1+0.5 0.6 A
PAMIO with 1x
PWM
0.1+0.1 0.2 A
PAMIO with 2x
2416
0.1+0.1+0.1 0.3 A
PAMIO with 2x
4ENC4A
0.1+0.5+0.5 1.1 A
PAMIO with 1x
2416 + 1x
4ENC4A
0.1+0.1+0.5 0.7 A
PAMIO with 1x
2416 + 1x
PWM
0.1+0.1+0.1 0.3 A
PAMIO with 1x
4ENC4A + 1x
PWM
0.1+0.5+0.1 0.7 A
NOTICE!
When the same power supply is used for the On-
Board logic and the digital inputs/outputs,
remember to add to the above values the output
currents required by the digital outputs.
Power Requirement
Power Requirement Of Standard
PAMIO Configurations
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 49
