The output LEDs are located in the input path and therefore show
the real state of the 24V outputs.
n if an output is HIGH, the corresponding LED is ON
n if an output is LOW, the corresponding LED is OFF
Fig. 34: PAMIO 2416 outputs status LEDs
Output Status LEDs
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 59
