PowerMetrix PowerMaster 3 Series User Manual

15 ANSI Specifications* (Model 3302)
AC Current Direct Channels
Channels
3 inputs, 0 to 20A
Accuracy
Range
Accuracy
Phase Error
1mA-10mA
10mA-100mA
100mA-20A
0.1% +200μV noise
0.1%
0.05%
n/a
n/a
±6mDeg
Resolution
0.000001A
AC Voltage Channels
Channels
3 inputs with Neutral reference; 10 to 600 Vrms
Accuracy
Range
Accuracy
Phase Error
20mV-500mV
500mV-5V
5V-46V
46V-600V
0.5% +2mV noise
0.5%
0.3%
0.05%
±10mDeg
±10mDeg
±3mDeg
±3mDeg
Resolution
0.000001V
AC Current Probe Channels
Channels
6 inputs for probes
Input Range
50mV to 3.2V
Accuracy
0.1% with ±3mDeg + E
probe
Probes Accepted
0.1mV/A to 100 mV/A, 0.00001mV/V to 1mV/V
Voltage output clamp-on current probes, flex probes, high voltage
current probes, primary voltage probes; power provided to
probes from system, calibration information stored in probe. Only
use probes meeting the manufacturer’s specifications. Using
probes that do not meet the manufacturer’s specifications may
lead to a safety hazard.
Calibrated Probe Range
Probe Model
Min
Max
MN375
0.5A
10A
MN353
5A
150
SR752
50A
1000A
FLEX
50A
1000A
Amp Litewire
50A
1000A
Resolution
Display determined by probe type
Rev 1.5 151
