2. Reinstall the Deck/Belt into the treadmill frame. Make sure to verify that the bottom of
the belt is not caught on any frame weldment brackets (GFX cushion brackets) or other
frame hardware that could impede belt movement.
3. Reinstall the two 5/32" hex key bolt front deck fasteners and torque to specification 27-
33 in-lbs (3.1-3.7 Nm). Its important to correctly torque these fasteners or they may
loosen with use. Retain fastener hardware for installation.
IMPORTANT: Its important to correctly torque the front deck fasteners at each deck
replacement and every PM
1
service interval. or the screws may prematurely loosen.
1
Preventative Maintenance: Daily, Weekly, Monthly, and Quarterly scheduled maintenance.
Experience Series 700 Line Treadmills
119
5 Replacement Procedures
Belt and Deck Replacement Procedure
