MC Fan Motor Connector
The fan motor interface cable connector is located under the MC top cover.
Component PIN Description
Fan motor 1 Black (24V GND)
2 Yellow (Fault_signal)
3 Red (+24 VDC)
Experience Series 700 Line Treadmills
90
5 Replacement Procedures
Motor Controller (MC) Replacement
