CONN
ID NAME PIN Description
6 RX
MTH DRIVE MOTOR THERMAL SWITCH 1 THERMAL SWITCH
SENSE
2 THERMAL SWITCH
SENSE
DBTH
1
DYNAMIC BRAKE RESISTER
THERMAL SWITCH
1 THERMAL SWITCH
SENSE
2 THERMAL SWITCH
SENSE
LIFT LIFT MOTOR PWR OUT & CONTROL 1 BLK - POTENTIOMETER
2 RED - POTENTIOMETER
3 NC
4 WHITE - MOTOR COMMON
5 WHITE - POTENTIOMETER
WIPER
6 NC
7 RED - MOTOR EXTEND
8 BLK - MOTOR RETRACT
GFX
1
not used - not used
Notes: 1) TRM800-14 treadmills only.
1
Ground Effects Impact Control Systtem: Patented treadmill design that out performs a nat-
ural running surface, absorbs high-impact movement, reduces joint stress and minimizes
fatique, and supports a solid adn controlled push off.
Experience Series 700 Line Treadmills
89
5 Replacement Procedures
Motor Controller (MC) Replacement
