Item Designation
1 Auger pump
2 Pressure flange
9. Remove the auger pump from the pressure flange.
8.6.6 Mounting the auger pump on the mixing pipe
This section describes how to mount the auger pump on the mixing
pipe. Observe the specifications in the “Maintenance intervals” sec‐
tion.
(Maintenance intervals P. 8 — 2)
See also the “Disassembling the pressure flange”
(Disassembling the
pressure flange P. 8 — 12)
section.
The following activities must be completed prior to assembly:
1. Switch off the power supply.
WARNING
Risk of crushing due to turning of the auger pump
Depending on the mounting position of the stator or screw conveyor
barrel, it can turn all the way to the stop when the machine is
switched on.
▶
Secure the machine against unauthorised or accidental starting.
▶
Never reach into the auger pump while switching the machine
on.
▶
For screw conveyor barrels with a stop, this must be secured at
the stop of the mixing pipe.
Maintenance
8 — 15
