2. Secure the machine against unauthorised starting.
Before mounting the auger pump on the mixing pipe, the mixer shaft
must be removed from the mixing pipe.
Item Designation
1 Turnbuckle
WARNING
Risk of crushing
▶
When opening the mixer motor, do not reach into moving com‐
ponents.
3. Open the turnbuckle to open the mixer motor.
4. Open the mixer motor sideways.
Maintenance
8 — 16
