Item Designation
1 Release lever
7. Hold the mixing pump securely using the handle on the drive mo‐
tor.
8. Push the release lever downwards.
⇒
The mixing pump can now be swivelled in its bracket.
Item Designation
1 Mixing pump
9. Swivel the mixing pump by approx. 90°.
10. Raise the mixing pump upwards out of the bracket.
11. Carefully set down the mixing pump and secure it against rolling.
Transport, setting up and connection
4 — 9
