12. Pull out the connector for the agitator motor on the control cabi‐
net.
Item Designation
1 Sealing pin
2 Toolbox
3 Base frame
4 Reservoir
13. Unlock the reservoir by pulling out the sealing pin (in the toolbox).
14. Pull the reservoir horizontally out of the base frame.
15. Carefully set down the reservoir so that it can neither roll away
nor be damaged.
Transport, setting up and connection
4 — 10
