Item Designation
1 Sealing pin
3. Secure the container using the sealing pin (in the toolbox).
4. Insert the connector for the agitator motor on the control cabinet.
Item Designation
1 Mixing pump
5. Raise the mixing pump into the mixing pump bracket from above.
6. Swivel the mixing pump by approx. 90°.
Transport, setting up and connection
4 — 12
