Item Designation
1 Release lever
7. Pull the release lever upwards.
Item Designation
1 Ring nut
8. Screw in the ring nut.
⇒
The mixing pump is now locked in its bracket.
9. Connect the electric cable for the mixing pump motor in the con‐
trol cabinet.
Transport, setting up and connection
4 — 13
