Quantum Data 780C User Manual

780C Multi-Interface Interoperability Tester – User Guide Page 9
September 29, 2014
Revision A1
2 Physical Interfaces of the 780C Multi-Interface Interoperability Tester
This section describes the administration, video and audio interfaces on the 780C test instrument:
2.1 Video Interfaces
Table 2-1 below describes the video interfaces on the 780C test instrument, these interfaces are used to render
test patterns for testing consumer electronic HDTVs and computer displays.
Table 2-1: 780C Video Interfaces
Video Interface
Description
HDMI (1) Output Type A
Single HDMI output connector. Supports HDMI 1.4x:
 Bit Depth: 24/30/36 bit.
 Colorimetry: RGB, YCbCr.
 Sampling: 4:4:4, 4:2:2, 4:2:0.
 Pixel rate: Timings up to 300MHz for 4K x 2K resolutions.
 DVI support through HDMI to DVI adapter cable (RGB, 4:4:4, 24 bit).
 Audio: LPCM, Dolby Digital and DTS (more details below).
HDBaseT (1) Output RJ-45
Single HDBaseT output connector. Supports HDBaseT 1.x:
 Bit Depth: 24/30/36 bit.
 Colorimetry: RGB, YCbCr.
 Sampling: 4:4:4, 4:2:2, 4:2:0.
 Pixel rate: Timings up to 300MHz for 4K x 2K resolutions.
 DVI support through HDMI to DVI adapter cable (RGB, 4:4:4, 24 bit).
 Audio: LPCM, Dolby Digital and DTS (more details below).
3G-SDI (1) Output BNC
3G-SDI output connector.
 Bit Depth: 24/30/36 bit.
 Colorimetry: YCbCr.
 Sampling: 4:4:2.
 Data rate: Timings up to 2.97Gbps.
 Audio: LPCM, Dolby Digital and DTS.
Analog Output – Component and VGA (HD15F)
 Bit Depth: 24 bit color depth.
 Colorimetry: RGB, YPbPr.
 Pixel rate: 80MHz.
 Sync types: separate and composite.
HDMI (1) Input Type A
Single link HDMI input connector. Supports HDMI 1.4x:
 Colorimetry: RGB, YCbCr.
 Sampling: 4:4:4, 4:2:2, 4:2:0.
 Pixel rate: Timings up to 300MHz for 4K x 2K resolutions.
HDBaseT (1) Input RJ-45
Single link HDBaseT input connector. Supports HDBaseT 1.x:
 Colorimetry: RGB, YCbCr.
 Sampling: 4:4:4, 4:2:2, 4:2:0.
 Pixel rate: Timings up to 300MHz for 4K x 2K resolutions.
3G-SDI (1) Input BNC 5
Single link HDMI input connector.
 Colorimetry: YCbCr.
 Sampling: 4:2:2.
 Data rate: Timings up to 2.97Gbps.
