Quantum Data 780C User Manual

780C Multi-Interface Interoperability Tester – User Guide Page 60
September 29, 2014
Revision A1
Table 4-6: Audio Pattern Tests
Pattern
Format
Interfaces
Range of Values
Auto Time Delay
Application:
 Fine tunes sound convergence
using the distance setting in an
AVR
Dolby Digital 5.1
HDMI
HDBASET
SPDIF
Optical
HDMI ARC (780C only)
 Individually selectable channels
 Cycle – cycling through each
channel; 8 seconds per channel
DTS-ES 6.1
HDMI
HDBASET
SPDIF
Optical
HDMI ARC (780C only)
4.7.3 Procedures for Testing a Display with Dolby Digital or DTS Sine Wave Clips
Table 4-7 below summarizes the 780C support for digital audio.
Table 4-7: Summary of Audio Sine Wave Clips
Sine Wave Audio Clips
Interfaces
Description
Dolby Digital Plus 7.1
HDMI
HDBASET
SDI
Provides a set of Dolby Digital Plus 7.1 sine wave clips:
 2.0 192kHz – 2 channel @ 192kHz sampling rate
 5.1 192kHz – 6 channel @ 192kHz sampling rate
 7.1 192kHz – 8 channel @ 192kHz sampling rate
Dolby TrueHD
HDMI
HDBASET
Provides a set of Dolby TrueHD Hi Bit Rate sine wave clips:
 192kHz 7.1 1kHz TrueHD – 8 channel @ 192kHz sampling rate
 192kHz 7.1 2kHz TrueHD – 2 channel @ 192kHz sampling rate
DTS HD HRA
HDMI
HDBASET
Provides a set of DTS-HD Hi Bit Rate sine wave clips:
 192kHz 7.1 5376kb HDHRA – 8 channel @ 192kHz sampling rate
 192kHz 5.1 3840kb HDHRA – 6 channel @ 192kHz sampling rate
 192kHz 7.1 5760kb HDHRA – 8 channel @ 192kHz sampling rate
DTS HD Master Audio
HDMI
HDBASET
Provides a set of DTS-HD Hi Bit Rate sine wave clips:
 192kHz 7.1 HDMA – 8 channel @ 192kHz sampling rate
 192kHz 5.1 HDMA – 6 channel @ 192kHz sampling rate
Use the procedures below for testing multi-channel Dolby or DTS sine wave using clips.
1. Make the cable connection between the appropriate the 780C video output connector (e.g. HDMI,
HDBaseT OUT, SPDIF or OPTICAL) and the input connector of the audio rendering device using the
cables supplied.
2. From the top level menu (shown in the figure below), select Audio Test Tone.
