Quantum Data 780C User Manual

780C Multi-Interface Interoperability Tester – User Guide Page 8
September 29, 2014
Revision A1
 Emulate the EDIDs on the 780C HDMI or HDBaseT Input port.
 Test runs automatically and flags improper handling. Checks for proper VIC, timing, video type, color depth
and sampling mode.
1.4.5 Auxiliary Channel Analyzer for DDC monitoring features
The following features are available with the Auxiliary Channel Analyzer test options:
 DDC monitoring with Auxiliary Channel Analyzer (ACA) – The 780C ACA enables you to monitor HDMI or
HDBaseT CEC DDC transactions such as HDCP and EDID as well as hot plug related events while
emulating an HDMI or HDBaseT source and/or an HDMI or HDBaseT sink device(s) in a system. You can
also monitor passively between two HDMI/HDBaseT devices. When monitoring passively you can also
view the +5V status.
1.4.6 What is in the 780C shipping box
The 780C instrument shipping container includes the items listed in Table 1-1 below:
Table 1-1: 780C Shipping Box Contents
Item Description
Part No.
780C Multi-Interface Interoperability Tester.
00-00236
12V DC (40 W) Power Supply / Adapter.
25-00106
Line cord for 12V Power Supply.
30A00400A03
Cable: HDMI-to-HDMI Type A.
30-00146
Cable: VGA to (3) RCA adaptor.
30-00203
Cable: USB.
30-00163
