Quantum Data 780C - Programming a Test Sequence in the UserKeys file

780C Multi-Interface Interoperability Tester – User Guide Page 233
September 29, 2014
Revision A1
401
Flat93
402
Flat87
403
Flat80
404
Flat73
405
Flat67
406
Flat60
407
Flat53
500
PRN24Bit
13.6 Programming a Test Sequence using the keypad
You can create and run test sequences in one of two ways.
 You can program a test sequence through the keypad using the procedures below.
 You can create a sequence by adding a set of commands to the UserKeys.txt file using the procedures
below.
Keypad functions are assigned as shown in Table 13-5 below:
Table 13-5 – Keypad Functions
Key
Function
Num Lock
TIMING - Select a format
/
PATTERN - Select an image
*
Program PROG – Create a sequence
. or Del
OUT or END
-
Go to Previous item
+
Go to NEXT item
1. Define a sequence as follows:
Note: Information after “//” are comments to help you understand.
OUT // press the OUT key to start the creation of the sequence
001 // enter the sequence number
PROG // press the PROG key to begin programming
TIMING
344 // 480p60 HDMI
PATTERN
001 // SmpteBar pattern
NEXT
TIMING
347 // 720p60 HDMI
PATTERN
004 // horizontal stair
NEXT
TIMING
