780C Multi-Interface Interoperability Tester – User Guide Page 232
Table 13-3 – Format Range per Interface Map
BNC + S-Video + CVBS (ED/HD)
13.5 Selecting a Test Pattern (Image)
A test pattern (image) can be selected by pressing the PATTERN key followed by the number that represents
the desired pattern. The following is an example of how you would select a test pattern using the Image Map
file shown in Table 13-4 below.
PATTERN
001
ENTER
This will display the SMPTEBar pattern at the current format and on the current interface. Then the “Previous”
and “Next” keys can be pressed to sequence through the pattern list.
Table 13-4 – Example Image Map File
To Next Page
