780C Multi-Interface Interoperability Tester – User Guide Page 62
September 29, 2014
Revision A1
5. Touch select the desired clip.
4.7.4 Procedures for Testing with Programmable Sine Waves
Use the procedures below for testing with programmable sine waves. Table 4-8 below describes the audio sine
wave parameters that can be configured.
Table 4-8: Sine Wave Audio Pattern
Pattern
Interface
Description
