780C Multi-Interface Interoperability Tester – User Guide Page 145
September 29, 2014
Revision A1
The Repeater Test screen will appear as shown below.
4. Touch select the OK activation button to initiate the test.
The test will run for up to about a minute. You will be instructed to switch to different timings and verify that the
video displayed on the 780C screen looks correct.
