Quantum Data 780C - Connection Configurations for Testing HDBaseT Links

780C Multi-Interface Interoperability Tester – User Guide Page 148
September 29, 2014
Revision A1
3. Touch select Link Test from Installer Tests from the Home menu shown below.
A diagram will appear on the 780C display depicting the proper setup for the Link Test.
4. Touch select the OK activation button to initiate the test.
