Table 12-1: List of Commands (alphabetical) – For Testing HDMI Sink Devices
Command
Description
Syntax
Parameters
Command Example
FRAT?
Queries the frame rate
of the outgoing HDMI
format.
FRAT?
Not Applicable
To read the frame rate of the
outgoing HDMI signal:
FRAT?
+60.000E+00
HDCP?
Runs an HDCP
authentication test on
an HDMI sink device
HDCP? <frames>
Number of frames:
Where frames is number of
frames rounded to the nearest
128 frames.
Results:
where results are:
0 = pass
1 = fail
To run an HDCP authentication
test on an HDMI sink device or
repeater device:
To run an HDCP test for 128
frames: (pass reported)
HDCP? 255
To run an HDCP test for 256
frames:
HDCP? 257
0
To run an HDCP test for 512
frames (with a failure reported):
HDCP?
1
HPAG?
Query the incoming
sink for hot plug pin
status.
HPAG?
<hotplug>
Where hotplug can be 0 (no hot
plug detected) or 1 (hot plug
deteted)
To check for hot plug on the
HDMI Out port:
HPAG?
HRAT
Sets the horizontal
rate of the video
timing.
HRAT <rate>
HRAT?
<rate>
Where rate can be within the
range of:
1000Hz to 130000Hz
To set the horizontal rate to
15000Hz:
HRAT 15000
ALLU or FMTU
HRES
Sets the horizontal
resolution of the video
timing.
HRES <pixels>
HRES?
< pixels >
Where pixels can be within the
range of:
100 to 4000 pixels
To set the horizontal resolution
to 1282 pixels:
HRES 1282
ALLU
HTOT
Sets the horizontal
total number of pixels
of the video timing.
HTOT <pixels>
HTOT?
< pixels >
Where pixels can be within the
range of:
100 to 4000 pixels
To set the horizontal total to
1376 pixels:
HTOT 1376
ALLU or FMTU
HSPP
Sets of the polarity of
the horizontal sync
pulse.
HSPP <polarity>
HSPP?
<polarity>
Where polarity can be within
the range of:
0 = high to low transition
1 = low to high transition
To set the horizontal sync pulse
polarity to low to high transition:
HSPP 1
ALLU or FMTU
HSPW
Sets the horizontal
sync pulse width of the
video timing in pixels.
HSPW <pixels>
HSPW?
< pixels >
Where pixels can be within the
range of:
1 to HTOT-HRES-HSPD
To set the horizontal sync pulse
width to 32 pixels:
HSPW 32
ALLU or FMTU
