780C Multi-Interface Interoperability Tester – User Guide Page 218
September 29, 2014
Revision A1
Table 12-1: List of Commands (alphabetical) – For Testing HDMI Sink Devices
Command
Description
Syntax
Parameters
Command Example
XAUD
Enables you to send
specific parameter
values of the AUD
infoframes out the
HDMI output
independent of the
HDMI audio stream.
XAUD:audparameter <value>
Where audparameter is one of the values identified
below and value is an allowed value associated with
the parameter provided in CEA-861-E.
CA – Channel assignment. Sets the channel
assignment value or retrieves the value transmitted.
CC – Channel count. Sets the channel count value
or retrieves the value transmitted.
CT – Audio coding type. Sets the audio coding type
value or retrieves the value transmitted.
SS – Sample size. Sets the sample size value or
retrieves the value transmitted.
SF – Sampling frequency. Sets the sampling
frequency value or retrieves the value transmitted.
DMI – Down-mix inhibit. Sets the down-mix inhibit
value or retrieves the value transmitted.
LSV – Level shift value. Sets the level shift value or
retrieves the value transmitted.
PBL – LFE playback level. Sets the LFE playback
level or retrieves the level transmitted.
CSUM – Checksum. Sets or gets the checksum
value for the corresponding InfoFrame.
To set the channel count to 3:
XAUD:CC 2
IFGU
To set the sampling size to 24:
XAUD:SS 3
IFGU
To return the value of the
channel count parameter type:
XAUD:CC?
XHVI
Enables you to send
specific parameter
values of the Vendor
Specific infoframe out
the HDMI output
independent of the
HDMI stream.
XHVI:hviparameter <value>
Where hviparameter is one of the values identified
below and value is an allowed value associated with
the parameter provided in CEA-861-E.
HVF – HDMI Video Format field. Values: 0 = no info,
i.e. 2D; 1 = 4Kx2K; 2 = 3D.
HVIC – HDMI Video Identification Code (VIC). Sets
VIC for 4Kx2K use.
H3DS– HDMI 3D structure. Sets the 3D structure
indication.
3DMG – 3D metadata present gate. Indicates
whether 3D metadata is present or not present.
3DED – 3D External data.
LEN – HDMI VSIF length in bytes.
CSUM – Checksum. Sets or gets the checksum
value for the corresponding InfoFrame.
To enable 3D:
XHVI:HVF 2
IFGU
To indicate that 3D metadata is
present:
XHVI:3DMG 2
IFGU
To query if 3D metadata is
present:
XHVI:3DMG?
