Table 12-6 below lists the format names, their resolutions and frame rates for television formats. For command
line control you would use the format name as the argument for the FMTL command.
Table 12-6: List of HDTV Format Names for Command Line
Applies to: HDMI, DVI (TV), Analog YPbPr Video Signal Types
Syntax for Format Name
Resolution
Frame Rates (Hz)
Command example
480i[frame rate] e.g.: 480i29
H: 720; V: 480
29.97, 30, 59.94, 60, 119.88, 120
FMTL 480i60
FMTU
480p[frameRate] e.g.: 480p59
H: 720; V: 480
59.94, 60, 119.88, 120
FMTL 480p60
FMTU
576i[frame rate] e.g.: 576i25
H: 720; V: 576
25, 50, 100
FMTL 576i25
FMTL
576p[frameRate] e.g.: 576p50
H: 720; V: 576
50, 100
FMTL 576p50
FMTU
720p[frameRate] e.g.: 720p25
H: 1280; V: 720
24, 25, 29.97, 30, 59.94, 60, 100,
119.88, 120
FMTL 720p60
FMTU
1080i[frameRate] e.g.: 1080i25
H: 1920; V: 1080
25, 29.97, 30, 50, 59.94, 60
FMTL 1080i59
FMTU
1080p[frameRate] e.g.: 1080p30
H: 1920; V: 1080
25, 29.97, 30, 50, 59.94, 60
FMTL 1080p60
FMTU
