Table 12-8: List of Image parameter names for command line
Image Name
Example
Image Name
Example
Image Name
Example
Raster
IMGL Raster
IMGU
Flat_Wht
IMGL Flat_Wht
IMGU
Linearity
IMGL Linearity
IMGU
DecodAdj
(Color Adjust)
IMGL DecodAdj
IMGU
Flat_Red
IMGL Flat_Red
IMGU
PRN24Bit
(pseudo noise)
IMGL PRN24Bit
IMGU
DecodChk
(Color Decode)
IMGL DecodChk
IMGU
Flat_Grn
IMGL Flat_Grn
IMGU
ZonePlate
(Moving zone plate)
IMGL ZonePlate
IMGU
ColorBar
(75 IRE)
IMGL ColorBar
IMGU
Flat_Blu
IMGL Flat_Blu
IMGU
User00/24
(User bitmaps)
IMGL User01
IMGU
Ramp
IMGL Ramp
IMGU
Flat_Cyn
IMGL Flat_Cyn
IMGU
Aux Combo Test
IMGL AuxTest
IMGU
Converge
IMGL Converge
IMGU
Flat_Mag
IMGL Flat_Mag
IMGU
