Quantum Data 780C - Procedures for Selecting an Resolution and Frame Rate - HDMI and HDBaseT

780C Multi-Interface Interoperability Tester – User Guide Page 23
September 29, 2014
Revision A1
The Signal Type menu appears as shown below.
3. Touch select the desired signal type using the associated activation button, example HDMI.
4. Touch select the options for the Signal Type. Use the information in Table 4-1 below as a guide:
Table 4-1: Signal Type
Signal Type Name
Physical Connector
Option
Option Values
HDMI
HDMI OUT via HDMI to
Color Space
 YCbCr 4:4:4, 4:2:2, 4:2:0
 RGB
