Accessory Connector (16 Channel Models Only) GM300 Radio Service Software Manual
6-10 6880902Z36-B October, 1996
Customizing the Expanded Accessory Connector
6
General I/O
RSS LOCATION
DEFINITION Designed to give the user the flexibility needed to support other accessories not
covered under the predefined packages. There are no dependent functions, which
leaves all pins open to be assigned an independent function of the user's choice.
DEFAULT/CHOICES Refer to Appendix H for Accessory Package defaults.
SEE ALSO External Accessories, Internal Accessories, DTMF Decoder Board
PROGRAMMING PROCEDURE
1. Press F4 at the MAIN MENU to get to the
CHANGE/VIEW CODEPLUG MENU.
4. Use the ↑ ↓ arrow keys to select General I/O.
2. At the CHANGE/VIEW CODEPLUG MENU,
press F2 to get to the RADIO-WIDE screen.
5. To customize the accessory package, press F9 to
get to the ACCESSORY CONNECTOR CON-
FIGURATION screen and make the desired
changes.
3. Press Tab or Enter/Return until the Acc. External
field is highlighted.
MAIN
MENU
➠
F4
➠
F2
CHANGE/
VIEW
➠
Tab
RADIO
WIDE
Acc. External
field
To Next Page
