Accessory Connector (16 Channel Models Only) GM300 Radio Service Software Manual
6-14 6880902Z36-B October, 1996
Customizing the Expanded Accessory Connector
6
Pin #
RSS LOCATION
DEFINITION This refers to the programmable pins on the Expanded Accessory Connector. Pins
can be INPUT and/or OUTPUT. Each programmable pin has a limited number of
functions that can be assigned to it. Pin numbers can not be programmed or
changed. Only the functions tied to pins can be changed. There are two types of
functions: Dependent and Independent. Dependent functions cannot be repro-
grammed. They are dependent on the assigned pin when used with the selected
accessory. Independent functions can be reprogrammed. Table 6-4 lists the input
& output capabilities of each pin, and the independent functions that can be
assigned to the various pins.
SEE ALSO Function Descriptions
Not Programmable with the RSS
To Next Page
