October, 1996 6880902Z36-B 4-13
GM300 Radio Service Software Manual Basic Features
GM300 Features
4
Tx Frequency
RSS LOCATION
DEFINITION A designated frequency in MHz for sending outgoing messages and signals from
the radio.
DEFAULT/CHOICES See Motorola catalog, price sheets or your service manual for valid Tx frequen-
cies.
RECOMMENDATIONS If you want a receive-only frequency, enter B, and transmit frequency will display
blank.
A “talk-around” frequency is entered by making the Tx frequency equal to the Rx
frequency.
If you type an invalid frequency, you'll hear a beep, and the original frequency
returns.
SEE ALSO Rx Frequency, Tx Squelch Code and Tx Squelch Type
PROGRAMMING PROCEDURE
1. Press F4 at the MAIN MENU to get to the
CHANGE/VIEW CODEPLUG MENU.
4. Press Tab (or Enter or Return) key until the Tx
Frequency field is highlighted.
2. At the CHANGE/VIEW CODEPLUG MENU,
press F5 to get to the
MODE CONFIGURATION
screen.
5. Type in the desired Tx Frequency in MHz. Be
sure to type in the decimal point too. (You can
scroll the list too.)
3. At the MODE CONFIGURATION screen, select
the mode number for which you want to pro-
gram the desired Tx Frequency by pressing
either the F3 or F4 keys until the desired mode
# is displayed in the Name field.
6. To change the Tx Frequency on other modes,
repeat steps 3-5.
MAIN
MENU
MODE
screen
CONFIG
field
Tx Frequency
➠
F4
➠
F5
➠
Tab
CHANGE/
VIEW
To Next Page
