October, 1996 6880902Z36-B 2-37
GM300 Radio Service Software Manual Getting Started
Setting (Configuring) RSS Computer Defaults
2
2.10.2 Setting a Default Port
Table 2-17. Setting a Port
Instruction What to type Explanation
1. Go to PC CONFIGURATION Press F3 at SETUP COMPUTER
CONFIGURATION MENU to go to
PC CONFIGURATION.
2. Go to serial port RIB field Pressing Ta b (or Enter or Return)
advances to the next field. Press Ta b
two times.
3. Select a port Use the arrow keys to scroll through
the available field options. Options
are
COM1 or COM2. Pick a port.
4. Test the port You can test the port by pressing F3,
COMM TEST - if ok it will beep and
in the Instruction Area (see number
2 in Figure 2-7) of the screen the
words “Radio Communications
OK” will appear.
5. Save this configuration F8 saves the field options on the
screen. “Saved” appears in Instruc-
tion Area of the screen.
6. Exit screen when done Press F10 to exit this screen and go
to previous menu.
F3
Tab
↓
F3
F8
F10
