GM300 Radio Service Software Manual Accessory Connector (16 Channel Models Only)
Customizing the Expanded Accessory Connector
6
Internal Accessories
RSS LOCATION
DEFINITION Refers to the accessories that are physically placed inside the radio and do not
actually use the connector. Connections are made internal to the radio, but still
use the pin functions.
DEFAULT/CHOICES Default: None.
Choices: ■ None ■ DTMF
DEPENDENCIES External Accessory MUST be Public Address, Remote, or General I/O in order to
select the DTMF Internal Accessory.
IMPORTANT NOTE The Internal Accessory should be installed in the radio before programming.
SEE ALSO External Accessories, DTMF Decoder Board
PROGRAMMING PROCEDURE
1. Press F4 at the MAIN MENU to get to the
CHANGE/VIEW CODEPLUG MENU.
4. Use the ↑ ↓ arrow keys to select the inter-
nal accessory.
2. At the CHANGE/VIEW CODEPLUG MENU,
press F2 to get to the RADIO-WIDE screen.
5. A popup warning asks if you have installed the
internal option board in the radio. If YES,
press F2. If NO, press F10 and install the
internal option board before proceeding.
3. Press Tab or Enter/Return until the Acc. Internal
field is highlighted.
6. If the External Accessory has been set to some-
thing other than Public Address, Remote, or
General I/O, another popup warning will
appear. You must Tab to the External Acces-
sory field and change this field to one of the
acceptable external packages.
MAIN
MENU
➠
F4
➠
F2
CHANGE/
VIEW
➠
Tab
RADIO
WIDE
Acc. Internal
field
