GM300 Radio Service Software Manual Accessory Connector (16 Channel Models Only)
Customizing the Expanded Accessory Connector
6
DTMF Decoder Board (internal only)
RSS LOCATION
DEFINITION
This internal accessory provides DTMF decode capabilities in the radio. It is an
internal board that must be installed before the radio accessory connector is pro-
grammed.
DEFAULT/CHOICES
Please refer to
Table 10-17 on page 10-13
,
Table 10-20 on page 10-14
, and
Table 10-22
on page 10-14
in Appendix H for defaults
EXCEPTIONS
When this internal accessory is installed, the external accessory packages that can
be used are Public Address, Remote, and General I/O.
SEE ALSO
Internal Accessories
PROGRAMMING PROCEDURE
1. Press
F4
at the
MAIN MENU
to get to the
CHANGE/VIEW CODEPLUG MENU
.
5. A popup warning asks if you have installed the
internal option board in the radio. If YES, press
F2
. If NO, press
F10
and install the internal
DTMF decoder option board.
2. At the
CHANGE/VIEW CODEPLUG MENU
,
press
F2
to get to the
RADIO-WIDE
screen.
6. If the External Accessory has been set to some-
thing other than Public Address, Remote, or
General I/O, another popup warning will
appear. You must
Tab
to the External Accessory
field and change the value to a compatible type.
3. Press
Tab
or
Enter/Return
until the Acc. Internal
field is highlighted.
7. To customize the accessory package, press
F9
to
get to the
ACCESSORY CONNECTOR CON-
FIGURATION
screen and make the desired
changes.
4. Use the
↑ ↓
arrow keys to select DTMF.
MAIN
MENU
➠
F4
➠
F2
CHANGE/
VIEW
➠
Tab
RADIO
WIDE
Acc. Internal
field
To Next Page
