Remote control commands

R&S

NRPxxP

103User Manual 1179.5760.02 ─ 02

If the pulse period, and thus the duty cycle, cannot be determined, NaN for "not a num-

ber" is returned.

Usage: Query only

SENSe<Sensor>:TRACe:MEASurement:TRANsition:POSitive:OCCurrence?

Queries the time when the signal passes through the medial reference power level with

rising edge, referenced to the delayed trigger event. Indicates the start point of the first

power pulse within the analysis window.

Usage: Query only

SENSe<Sensor>:TRACe:MEASurement:TRANsition:SPERiod?

Queries the number of samples per second.

Usage:

Query only

8.9.5.2 Power-related pulse analysis results

Remote commands:

SENSe<Sensor>:TRACe:MEASurement:POWer:AVG?..................................................... 103

SENSe<Sensor>:TRACe:MEASurement:POWer:HREFerence?......................................... 104

SENSe<Sensor>:TRACe:MEASurement:POWer:LREFerence?..........................................104

SENSe<Sensor>:TRACe:MEASurement:POWer:MAX?.....................................................104

SENSe<Sensor>:TRACe:MEASurement:POWer:MIN?......................................................104

SENSe<Sensor>:TRACe:MEASurement:POWer:PULSe:BASE?........................................ 104

SENSe<Sensor>:TRACe:MEASurement:POWer:PULSe:DROop?......................................105

SENSe<Sensor>:TRACe:MEASurement:POWer:PULSe:TOP?.......................................... 105

SENSe<Sensor>:TRACe:MEASurement:POWer:REFerence?............................................105

SENSe<Sensor>:TRACe:MEASurement:TRANsition:NEGative:OVERshoot?...................... 105

SENSe<Sensor>:TRACe:MEASurement:TRANsition:POSitive:OVERshoot?........................105

SENSe<Sensor>:TRACe:MEASurement:POWer:AVG?

Queries the average power during the time in which the pulse is active.

Usage:

Query only

Querying measurement results
