Remote control commands
R&S
®
NRPxxP
61User Manual 1179.5760.02 ─ 02
Parameters:
<count> Range: 1 to 16
*RST: 8
SENSe<Sensor>:[POWer:]TSLot[:AVG]:WIDTh <width>
Sets the length of the timeslot. See Figure 8-3.
Parameters:
<width> Range: 50.0e-9 to 0.10
*RST: 1.000e-3
Default unit: Seconds
SENSe<Sensor>:[POWer:]TSLot[:AVG][:EXCLude]:MID:OFFSet[:TIME] <time>
Determines the distance from the start of the timeslots to the start of the interval to be
blanked out. See Figure 8-3.
Parameters:
<time> Range: 0.00 to 0.10
*RST: 0.00
Default unit: Seconds
SENSe<Sensor>:[POWer:]TSLot[:AVG][:EXCLude]:MID:TIME <time>
Sets the length of the time interval in the timeslots to be excluded from the measure-
ment. See Figure 8-3. The parameter applies to each individual timeslot.
Note: Even if the exclusion interval exceeds the timeslot because, for example, its right
limit is outside the timeslot, correct results are obtained. In the extreme case, where
the interval length has been set to a value greater than the timeslot length, 0 W is out-
put as the measured power. No error message is output.
Parameters:
<time> Range: 0.00 to 0.10
*RST: 0.00
Default unit: Seconds
SENSe<Sensor>:[POWer:]TSLot[:AVG][:EXCLude]:MID[:STATe] <state>
Enables or disables the blanking out of time intervals in the timeslots.
Parameters:
<state> *RST: OFF
8.6.4 Trace measurement
The trace measurement determines the course of power over a defined time. During
the measurement time set by SENSe<Sensor>:TRACe:TIME, a large number of mea-
Configuring the measurement modes
